The lightweight and quick miniwelder geo2 from Weldy is suitable to weld geomembranes ranging from 0.5 - 1.5 mm thickness (HD-PE 0.4–
1.0 mm; TPO 0.7 – 1.5 mm). It can be used to weld fish farm tanks, water tanks, in gardens, foundations and many other industrial areas. The miniwelder geo2 distinguishes itself through its revolutionary drive technology and its intuitive operation. The temperature and speed can easily be activated and deactivated with two buttons and adjusted using two dials. The current process status is displayed by two LEDs.
Technical Data
Metric
Imperial
Article
154.884
Voltage
230 V
Frequency
50/60 Hz
Power
800 W
Temperature
60 - 480 °C
Speed
0.4 - 7.5 m/min
Welding Technology
Hot wedge
Hot wedge length
50 mm
Hot wedge width
36 mm
Hot wedge material
Stainless steel
Max. overlap
100 mm
Weld seam width
2 x 12 mm / 2 x 0.47 in
Roll material
Steel roller sharp straight
LQS
The device features LQS (Leister Quality System) data recording
No
Display
No
Length
228 mm
Width
228 mm
Height
170 mm
Weight
3.9 kg
Welding materials
CSPE; FPO; HDPE; LDPE; LLDPE; PE; PVC
Weldable material thicknesses
The weldable material thickness depends on the material type and its properties.
